Y Type Forged Globe Valve

A Y Type Forged Globe Valve is a specialized type of globe valve designed to minimize pressure drop and optimize flow efficiency in high-pressure and high-temperature applications. Its unique Y-shaped body design allows for a more streamlined flow path compared to traditional globe valves, making it ideal for systems where pressure loss must be minimized. The valve is constructed from forged steel, ensuring durability and strength in demanding environments.

Request a Quote

Download

Product Description

Product Details

Technical Specifications:

Design standard: ASME B16.34、GB/T 12235、BS1873
Face to face standard: ASME B16.10、GB/T 12221
Flange ends: ASME B16.5、GB/T 9113
Pressure test:API 598、GB/T 13927

Product Specifications:

Body material: carbon steel, stainless steel, alloy steel
Nominal diameter: 1/2"～2"（DN15~DN50）
Pressure range: Class150～2500（PN10~PN420）
Working temperature:-196℃～560℃
Operation : wrench, worm gear, electric,etc.

Design Features:

• Straight through, small flow resistance;
• Sealing surface adopts spherical surfaces, bringing linear contact between the sealing faces, while guaranteeing reliable tightness and preventing scarring;
• High abrasion-resisting and erosion-proof performances;
• The valve is designed as a back seal structure, ensuring no medium leakage occurs in the stuffing box, reliable tightness and online replacement of packing;
• Its valve stem sealing is realized by collaboration of flexible and woven graphite, ensuring a more reliable tightness.

Application:

Chemical fertilizer, mining, metallurgy, aluminum oxide and other industries
